In my previous article, I have written about a content-based recommendation engine using TF-IDF for Goodreads data. In this article, I am using the same Goodreads data and build the recommendation engine using word2vec.

Like the previous article, I am going to use the same book description to recommend books. The algorithm that we use always struggles to handle raw text data and it only understands the data in numeric form. In order to make it understand, we need to convert the raw text into numeric. This can be achieved with the help of NLP by converting the raw text into vectors.

I used TF-IDF to convert the raw text into vectors in the previous recommendation engine. However, it does not capture the semantic meaning and also it gives a sparse matrix. Research and breakthroughs are happening in NLP at an unprecedented pace. Neural network architectures have become famous for understanding the word representations and this is also called word embeddings.

Word embedding features create a dense, low dimensional feature whereas TF-IDF creates a sparse, high dimensional feature. It also captures the semantic meaning very well.

One of the significant breakthroughs is word2vec embeddings which were introduced in 2013 by Google. Using embeddings Word2vec outperforms TF-IDF in many ways. Another turning point in NLP was the Transformer network introduced in 2017. Followed by multiple research, BERT (Bidirectional Encoder Representations from Transformers), many others were introduced which considered as a state of art algorithm in NLP.

This article explores how average Word2Vec and TF-IDF Word2Vec can be used to build a recommendation engine. I will explore how BERT embeddings can be used in my next article.

What is Word2Vec?

Word2Vec is a simple neural network model with a single hidden layer. It predicts the adjacent words for each and every word in the sentence or corpus. We need to get the weights that are learned by the hidden layer of the model and the same can be used as word embeddings.

Let’s see how it works with the sentence below:

From the above, let’s assume the word “theorist” is our input word. It has a context window of size 2. This means we are considering only the 2 adjacent words on either side of the input word as the adjacent words.

Now, the task is to pick the nearby words (words in the context window) one-by-one and find the probability of every word in the vocabulary of being the selected adjacent word. Here, the context window can be changed as per our requirement.

Word2Vec has two model architectures variants 1) Continuous Bag-of-Words (CBoW) and SkipGram. Internet is literally flooded with a lot of articles about Word2Vec, hence I have not explained in detail. Please check here for more details on Word2Vec.

In simpler terms, Word2Vec takes the word and gives vector in D-dimensional space.

Please note, Word2Vec provides the word embeddings in low dimensional( 50–500) and dense (it’s not a sparse one, most values are non-zero). I used 300 dimension vectors for this recommendation engine. As I mentioned above, Word2Vec is good at capturing the semantic meaning and relationship.

Training our own word embeddings expensive process and also need large datasets. I don’t have a large dataset as I scrapped Goodreads data only pertains to the genre: business and cooking. Used Google pre-trained word embeddings which were trained on a large corpus, such as Wikipedia, news articles etc.

The pre-trained embeddings helped to get the vectors for the words you want. It is a large collection of key-value pairs, where keys are the words in the vocabulary and values are their corresponding word vectors.

In our problem, we need to convert the book descriptions into a vector and finding the similarity between these vectors to recommend the book. Each book description is a sentence or sequence of words. I have tried two methods such as Average Word2vec and TF-IDF Word2Vec.

Average Word2Vec

Let’s take some random description example in our dataset

Book title: The Four Pillars of Investing’Book Description:william bernstein american financial theorist neurologist research field modern portfolio theory research financial books individual investors wish manage equity field lives portland oregon

OK, how to convert the above description into vectors? As you know, word2vec takes the word and gives a d-dimension vector. First, we need to split the sentences into words and find the vectors representation for each word in the sentence.

The above example has 23 words. Let’s denote the words as w1, w2, w3, w4 …w23. (w1 = william, w2 = bernstein ………. w23 = oregon). Calculate Word2Vec for all the 23 words.

Then, sum all the vectors and divide the same by a total number of words in the description (n). It can be denoted as v1 and calculate as follow

Here, vectors are in d -dimensional (used 300 dimensions)

N = number of words in description 1 (Total: 23)

v1 = vector representation of book description 1.

This is how we calculate the average word2vec. In the same way, the other book descriptions can be converted into vectors. I have implemented the same in Python and code snippets have given below.

TF-IDF Word2Vec

TF-IDF is a term frequency-inverse document frequency. It helps to calculate the importance of a given word relative to other words in the document and in the corpus. It calculates in two quantities, TF and IDF. Combining two will give a TF-IDF score. A detailed explanation of how TF-IDF work is beyond the scope of this article as it is flooded with many articles on the internet. Please check here for more details on TF-IDF.

Let’s see how TF-IDF Word2Vec works,

Consider the same description exampleBook Description:william bernstein american financial theorist neurologist research field modern portfolio theory research financial books individual investors wish manage equity field lives portland oregon

Again, the description has 23 words. Let’s denote the words as w1, w2, w3, w4 …w23. (w1 = william, w2 = bernstein …. …..w23 = oregon).

Steps to calculate the TF-IDF Word2Vec:

1. Calculate the TF-IDF vector for each word in the above description. Let’s call the TF-IDF vectors as tf1, tf2, tf3…tf23. Please note TF-IDF vector won’t give d-dimensional vectors.
2. Calculate the Word2Vec for each word in the description
3. Multiple the TF-IDF score and Word2Vec vector representation of each word and, total the same.
4. Then, divide the total by sum of TF-IDF vectors. It can be called as v1 and written as follow

v1 = vector representation of book description 1. This is the method for calculating TF-IDF Word2Vec. In the same way, we can convert the other descriptions into vectors. I have implemented the same in Python and code snippets have given below.

Content-based recommendation system

A content-based recommendation system recommends books to a user by taking similarity of books. This recommender system recommends a book based on the book description. It identifies the similarity between the books based on its description. It also considers the user’s previous book history in order to recommend a similar book.

Example: If a user likes novel “Tell me your dreams” by Sidney Sheldon, then the recommender system recommends the user to read other Sidney Sheldon’s novels or it recommends novel with the genre “Non-fiction”. (Sidney Sheldon novels belong to Non-fiction genre).

We need to find similar books to a given book and then recommend those similar books to the user. How to find whether the given book is similar or dissimilar? A similarity measure was used to find the same. Cosine Similarity was used in our recommender system to recommend the books. For more details on the similarity measure, please refer to this article.

As I mentioned above, we are using goodreads.com data and don’t have users reading history. Hence, I am not able to use a collaborative recommendation engine.

Data

I scraped book details from goodreads.com pertaining to business, non-fiction, and cooking genres.

Code

Output

The data consist of 2382 records. It has two genres, 1) Business (1185 records) 2) Non-Fiction (1197 records). Also, it consists of Book title, description, author name, rating, and book image link.

Text Preprocessing

Cleaning the book description and stored the cleaned description in a new variable called ‘cleaned’

Recommendation Engine

Building two recommendation engine using Average Word2Vec and TF-IDF Word2Vec word embeddings.

Average Word2Vec

Splitting the descriptions into words and stored in a list called ‘corpus’ for training our word2vec model

Training our corpus with Google Pretrained Word2Vec model.

Created a function called vectors for generating average Word2Vec embeddings and stored the same as a list called ‘word_embeddings’. The code follows the steps which I have written in the above-average word2vec explanation.

Top 5 Recommendation using Average Word2Vec

Let’s recommend the book “The Da Vinci Code” by Dan Brown

The model recommends other Dan Brown books based on the similarity existing in the book description.

Let’s recommend the book “The Murder of Roger Ackroyd” by Agatha Christie

This book belongs to Mystery thriller and it recommends a similar kind of novels.

Building TF-IDF Word2Vec Model

The code explains the same steps which I mentioned above the process of TF-IDF Word2Vec model. I am using the same corpus only change in the word embeddings

Building the TF-IDF model

Building TF-IDF Word2Vec Embeddings

Top 5 Recommendation using TF-IDF Word2Vec

Let’s recommend the book “The Da Vinci Code” by Dan Brown

We can see the model recommends Sherlock homes novel and the output is different from the average word2vec.

Let’s recommend the book “The Murder of Roger Ackroyd” by Agatha Christie

Again it recommends different from the average word2vec. But it gives a similar novel to the Agatha Christie.

It seems TF-IDF Word2Vec gives powerful recommendation than average word2vec. This article only explores how to use average Word2Vec and TF-IDF Word2Vec to build a recommendation engine. Not comparing the results between these two models. The data that I have used is very minimum and definitely the result would change when we deal with the larger dataset. Also, we can use Fast Text (from Facebook) and Glove (from Stanford) pre-trained word Embeddings instead of Google one.

Real-world recommendation systems are more robust and advanced. A/B testing was used to evaluate the recommendation engine and also business domain plays a major role in the evaluation and, picking of the best recommendation engine.

In my next article, I will show how to use BERT embeddings to build the same type of recommendation engine. You can find the entire code and data in my GitHub repo.

Thanks for reading. Keep learning and stay tuned for more!
